Engineered with a special Imaging glass optical lens group, our
200W COB LED imaging light delivers razor-sharp
beam definition (19°/26°/36° standard, 14°-50° customizable). The
STM32 control chip ensures pixel-perfect DMX512
integration for synchronized stage setups, while 16k Hz output
frequency eliminates flicker in 4K/8K broadcast
environments. With CRI≥95 and dual 3200K/5600K modes, achieve
cinema-grade color accuracy for hybrid live-
streamed performances. The MGCP heat pipe + silent fan system
maintains ≤20℃ temperature rise during 12
hours opera rehearsals.
Product parameters
| WOP-STPROFILE200 | Bi-Color 2 in 1
100W+100W COB LED single color full on only 100W, both color full
on 200W |
| Voltage: | AC 90~240V, 50/60Hz |
| Max Power Consumption: | 200W |
| Lamp source: | 1 pcs Citizen 200w COB LED |
| Beam angle: | 19°/26°/36° Optional ( 14°/50° customizable) |
| Optical lens: | special Imaging glass optical lens group (6 unique glasses, image
is clear and even, no blue edges) |
| Adjustable Color Temperature: | 3200K; 5600K |
| Color Temperature deviation: | ±5% |
| Color rendering index: | CRI 95 Ra |
| Manual Dimmer: | 0-100% |
| Dimming Frequency: | 8k/Hz |
| Max Clock frequency: | 72m/Hz |
| Control mode: | 16 Bit dimming,STM32 control chip,DMX512 |
| Channel mode.: | 1/3/5Ch |
| Cooling: | MGCP heat pipe radiator + Silent fan for heat dissipation,no noise.
Temperature rise does not exceed 20 ℃, intelligent automatic
temperature adjustment system |
| Tilt angle: | ± 90 ° center of gravity adjustable by Orbital bracket |
| Display | LCD Display |
| Light barrier: | Four-leaf(supply for requirement) |
| Weight of light barrier: | 0.5kg |
| Fixture Size: | 680×350×480mm |
| N.W: | 12KG |
| G.W: | 14KG |
Product advantages:
- Quality Citizen COB led source
- 3 color options
- High color rendering index of 92 Ra
- Quite operation
- Long life of the whole item
Applications:
Entertainment: dance halls, night clubs, Wedding, Events, DJ,
Disco, club, KTV, pub, bar, family party, dance hall, theatre,
studio and other entertainment centers …
FAQ:
Q: Do your products have CE & Rohs certificates?
A: Yes. All of our products pass CE & Rohs.
Q: What is your warranty policy?
A: We provide One Year Warranty for all of our products. Or even
longer warranty service for some special items.
Q: Do you accept sample order?
A: Yes. Trial test order of small quantity is acceptable.
Q: Can I have better price?
A: As a manufacturer, we have different price policy for different
sizes of orders. If you have demand on big quantity, please contact
us for the discount.
Q: What kind of payment term do you accept?
A: Payment terms options available for you like: T/T, Western
Union,Paypal , Moneygram.
Q: How long I can receive my merchandise? What shipping methods I can choose?
A: Usually it takes 3 to 7 days to reach you. While you can choose
to ship under UPS, DHL, TNT, EMS etc. You will get tips on shipping
from us as we know better of which shipping company has advantage
in customs clearance and more efficient delivery in your country.
Q: How can I track my packages?
A: A tracking number will be sent to you in 24 hours after sending
out the goods, with which you can track on your local express
website.
Q: If any problem occurred on the product, how should I do?
A: Please kindly be noted that all products must be tested for 48
hours before shipping to our customers. If any problem occurred
during use, please help to take a small video and pictures which
reflect the problem in clear way, send to us, our engineers will
sort out the problem soon, then provide you the right sulotion, or
spare parts can be sent to you for free.
